SKU: SS105P160Q
1.20 Tonne - Spout Top Spout Bottom - Baffle Bulk Bag - 105 x 105 x 160 CM
1.20 Tonne - Spout Top Spout Bottom - Baffle Bulk Bag - 105 x 105 x 160 CM
Couldn't load pickup availability
Description
Description
This baffle FIBC is built for dense, space-efficient loads. The 105 × 105 × 160 cm body with internal baffles helps the bag hold a square profile for pallet fit and stable stacking, with a 1200 kg SWL and 5:1 safety factor for single-trip applications.
- Bag size: 105 × 105 × 160 cm (internal)
- Configuration: Spout top, spout bottom
- SWL: 1200 kg
- Safety factor: 5:1 (single trip)
- Bag type: Baffle bulk bag
- Top spout: 40 × 50 cm
- Bottom spout: 40 × 50 cm
- Loops: 4 × cross-corner, 30 cm free height
- Document pocket: 1 × A4
Specifications
- Internal dimensions: 105 × 105 × 160 cm
- Safe Working Load: 1200 kg
- Safety factor: 5:1 (single trip)
- Structure: Baffle construction for square fill
- Filling: Spout top, 40 × 50 cm
- Discharge: Spout bottom, 40 × 50 cm
- Lifting: 4 × cross-corner loops, 30 cm free height
- Docs: A4 document pouch
Manufactured to ISO 21898:2024 guidance for flexible intermediate bulk containers (FIBCs).
Materials & usage
Material: Woven polypropylene (PP), baffle panels maintain square footprint for better palletisation and freight efficiency.
Usage: Suited to dry bulk materials where controlled fill and discharge are needed, including grains, pellets, resins, minerals, and recyclables. Ensure compatible filling frame and discharge station.
- Inspect fabric, seams, and loops before each use.
- Lift using all four loops simultaneously with rated tines or a spreader bar.
- Do not exceed SWL, and do not reuse beyond intended single trip.
- Store clean and dry, away from prolonged UV exposure when not in service.
FAQs
What does “baffle bag” mean?
Internal baffles control the bag’s shape as it fills, keeping a near-square profile to optimise pallet space and stacking stability.
Is this bag reusable?
It is rated 5:1 for single trip. For multi-trip applications, enquire about 6:1 designs.
How do I discharge safely?
Use a compatible discharge station. Close off flow as required, and keep personnel clear of the discharge zone.
Specifications
Specifications
| Length | 105 |
|---|---|
| Width | 105 |
| Height | 160 |
| SWL | 1200 KG |
